Features:-
>Premium Dual DAC Chipset.
>Two ES9219C Sabre DAC Chips.
>High-power output.
>Independent Femtosecond Oscillator.
>Supports high-resolution PCM and DSD signals.
>Full 16x MQA decoding.
>Multi-colour LED indicator.
>Clean and accurate performance with high SNR and Low Distortion ratings.
>Dual headphone outputs(3.5mm single-ended+4.4mm balanced).
>Detachable Type-C connector cable.
Technical Specifications:-
>PCM signal support: Up to 32-Bit/384kHz.
>DSD signal support: Native DSD256.
>MQA signal: 16x unfolding.
>Dimensions: 23mmx50mm.
>Weight: 23grams.
Output Parameters(4.4mm):-
>THD+N: 0.00035%(600Ω), 0.0005%(32Ω).
>Output voltage: 3.2Vrms(32Ω), 4Vrms(300Ω).
>SNR: 123dB.
>Dynamic Range: 123dB.
>Frequency Response: 20Hz-40kHz.
>Output Impedance: <0.5Ω.
Output Parameters(3.5mm):-
>THD+N: 0.00056%(600Ω), 0.0007%(32Ω).
>Output voltage: 2Vrms(32Ω).
>SNR: 120dB.
>Dynamic Range: 120dB.
>Frequency Response: 20Hz-40kHz.
>Output Impedance: <0.3Ω.
iBasso DC06, the sixth generation of the famous DC series of Portable USB DAC/AMPs is finally here. Packed with a premium Dual DAC chipset from ESS Sabre Technologies, the DC06 provides excellent performance in audio signal decoding. It is supported by an independent femtosecond crystal oscillator. The compact DC06 features both single-ended and balanced headphones with its 3.5mm SE and 4.4mm Bal output ports. With the help of high-quality Sabre DAC chips, the DC06 achieves ultra-low distortion and high SNR ratings promising a clean and detailed output for the users!!
Premium Sabre DAC Chipset:-
iBasso DC06 adopts a premium Dual DAC configuration for audio signal decoding. It houses two ES9219C DAC chips from ESS Sabre Technologies. ES9219C is a premium 32-bit stereo DAC chip from Sabre Technologies that features their Quad DAC+ technology. It provides excellent performance in decoding high-resolution audio signals and presents a clean and precise sound for its users.
Ultra-Compact High-Resolution Audio Signal Decoder:-
iBasso DC06 is a very compact device. It’s just 23mm in width and 50mm in length and weighs only 23 grams. But don’t get fooled by its compact size, the DC06 decodes high-resolution signals with perfection. It supports high-resolution 32-Bit/384kHz PCM and native DSD256 signals. The DC06 also supports full 16x unfolding for high-resolution MQA signals.
Supports Both Single-Ended As Well As Balanced Headphone Connections:-
iBasso DC06 supports both single-ended as well as balanced headphones. It has a single-ended 3.5mm headphone output and another 4.4mm balanced headphone output. Users can use their IEMs and Headphones with both the terminations easily.
Easily Power Your IEMs/Headphones With Powerful Output Rating Of DC06:-
DC06 has got a powerful amplification section underneath its shell. It provides a whopping 320mW of clean output at 32Ω of load. This is ideal enough for most IEMs and some low-power requiring headphones and drives them easily off your smartphones.
Multi-Colour LED Indicator Light:-
iBasso has placed a multi-color LED indicator near the headphone output ports. It glows in different colors depending on the active file bitrate like Red on standby, Blue on DSD, Green on PCM, and Magenta on MQA.
